Sunday 11th May
Middle and Upper Jurassic rocks in the area around Sutton Bank and the Howardian Hills.

Leaders:  John Powell and Jon Ford (BGS), coming from Nottingham.
Met at 10.00 a.m. Sutton Bank Visitor's Centre
Full report by Christine Burridge can be found in the June 2014 Newsletter.

Below is a summary
Under the excellent guidance of the leaders the following localities were visited:

Sutton Bank 451483
Regional and topographical overview of geological setting. Roulston Scar (Upper Jurassic Lower Calcareous Grit on left of photo; Hood Hill towards centre , separated from Roulston Scar by a Quaternary glacial melt water channel. Flat lying Vale of York in the distance covered by Quaternary deposits overlying Permo-Triassic sediments. Features of interest from this vantage point are the Middle and Upper Jurassic rocks forming the escarpment and outliers, and the absence of the Oxford Clay around Roulston Scar which has influenced the style of landslides, including the lack of cambering in this area.



Shaw's Gate Quarry (SE 5240 8220)
Shaw's Gate Quarry  Spectacular contemporaneous deformation structures, scouring and sedimentological features in the lower part of the Hambleton Oolite (Upper Jurassic; Corallian Group). Evidence for debris flows, de-watering, scouring, convolute bedding, soft-sediment deformation and injection dykes, were attributed to highly mobile ooidal shoals deposited in shallow water towards the shelf edge, possibly influenced by contemporaneous seismic activity resulting from local tectonics.

Raven's Gill SE452481
A unique unconformity: Oldstead oolite directly overlying Kellaways Rock.
Due to uplift during or after deposition of the Kellaways Rock, Oxford Clay was either completely eroded away or not deposited. The time gap represented by the unconformity is equivalent to about six ammonite zones of the full coastal succession.

Mowthorpe Quarry SE468468

Originally mapped by Fox-Strangways as an atypical lithofacies of the Dogger Formation, the limestone includes the bryozoan Haploecia straminea (now Collapora straminea) normally associated with, and typical of, the much later transgressive marine unit, the Lebberston (Millepore/Whitwell Oolite) Member, (Middle Jurassic, Cloughton Formation). Discussion took place as to whether the exposure is a local, and atypical carbonate lithofacies of the heterogeneous Dogger Formation (Aalenian), or does it represent local downcutting of the Lebberston Member (early Bajocian) influenced by tectonics associated with the Market Weighton High. On balance, the weight of opinion favoured the former, since the Dogger is also known to exhibit local carbonate lithofacies near Sutton Bank (Powell et al, 1992).

Hand specimen and microscope photo of a cross section  of Collapora straminea as seen at Mowthorpe Quarry



Burythorpe Quarry SE478465
The quarry is being worked for silica (moulding) sand and exposes an excellent section in the Osgodby Formation (Callovian). Here, the unit is very different from the lithology seen earlier in Raven's Gill, and comprises soft, very well sorted, fine-grained, white-grey sand with very large (up to 'car-size') carbonate-cemented nodules (concretions). Some of the latter contain ammonites (Cardioceras sp.) as seen in the photo to the left.







Top of page

 July 5th Lady Cross Quarry and Blanchland, Leaders, Eric Johnson and Robin Turner. Full report in July 2014 Newsletter.
20th July Austwick and Crummackdale. Leader: Eric Johnson  Full report in September 2014 Newsletter
12th October Geology of the Nenthead area Leaders: Peter Jackson and Brian Young: Full report in November 2014 Newsletter. See also references to Further Reading on Geology and Mineralisation at Nenthead.
25th October Geology of Durham Cathedral. Organised as a formal Cathedral tour. Leader: Brian Young (retired BGS/ Durham University)
